Product Highlights
- Frost-resistant 640x480 AMOLED display (XP Models)
- 8-color palette for imaging customization
- Range of detection of up to 2000 yards
- Built-in photo and video recorder
- Stream Vision App compatible
- Three different models: XP28, XP38 and XP50
Reinforced housing
High Resolution
The Lexion XP boasts an uncooled micro-bolometric matrix 640x480px, at 17 µm, for highly detailed imaging.
Long Viewing Range
Actual range of detection of a human figure (1.8x0.5m) in the field (human has outerwear, in the field against the background of the forest) for the Lexion thermal scopes up to 1800 meters, depending on the model.
Integrated Video Recorder
The Lexion is equipped with a recorder which enables video shooting and image capturing at the time of observation. Video and photo files saved in the internal memory can be transferred to a PC/laptop via wired or Wi-Fi connection
Stadiametric Rangefinder
Lexion has a stadiametric rangefinder performed in the shape of rangefinding reticle which enables distance measuring to observed objects with known height 1,7m, 0,7m, 0,3m with a sufficient precision.
Mobile-Friendly with Remote Control and Live Internet Streaming
The highlight of the Lexion is the ability to link via Wi-Fi the device with Android and iOS based mobile units using the free mobile application Stream Vision. The Stream Vision software connects the device with Android / iOS mobile unit (smartphone or tablet) which enables you to receive footage in the real time mode, to distantly operate the device with your smartphone, as well to stream online the image captured by the device to Youtube.
Fully Waterproof
The Lexion thermal scopes can be operated in precipitation of any intensity, e.g. heavy shower or snowfall (the units have IPX7 degree of protection according to the IEC 60529).
External Power Supply
Lexion makes charging from external sources, such as power banks, fast and easy with a micro-USB jack. The convenience of power-bank charging even enhances the ability to power up the Lexion during extremely cold weather while also protecting the source from rapid discharge.
More features
B-Pack Power Supply System
Lexion includes a progressive autonomous B-Pack power supply consisting of a quick-detach, rechargeable IPS5, 5A-h battery pack designed to deliver over 8 hrs. of operation on maximum mode. Higher-powered IPS7, IPS10 or IPS14 battery packs, as well as AA battery case (included), also are available and provide a perfect off-the-grid power solution.
High Image Frequency
Due to the high image frequency (50hz) it is comfortable to use thermal camera dynamically (during rapid moving of observer or object of observation).
Color Palettes
In addition to user-favorite “white hot” and “black hot” imaging, Lexion offers a robust array of 8 color palettes for true colorized temperature mapping. Transitioning from color to default “white hot” during operation is also fast and easy.
Display-Off
When it is necessary to temporarily stop observation the user can apply Display Off function. It provides the necessary level of camouflage (no light from the eyepiece of the device) between observation sessions as well as the fast restart of observation (when display is turned off, all other systems are working; for normal operation it is enough just to power on the display again).
Wide Range of Operating Temperatures
Lexion thermal imaging scopes are effective for the use in low temperatures (-25°C) thanks to the frost-resistant AMOLED display employed in the unit (image remains the same as when viewing at positive temperature of the surrounding atmosphere).
Effective Temperature Stabilization of the Sensor
A radiator panel, located on the device’s body, effectively prevents heat build-up from the sensor and other components while also significantly reducing temperature and noise sensitivity, especially between calibrations.
Updatable Software
For initial setup and additional updates, the iOS and Android compatible Stream Vision App ensures the most recent Lexion software versions are available.
Wireless Remote Control (optional)
The ergonomic, wireless remote control, with encoder wheel, puts the full range of Lexion operation at your fingertips when comfort and convenience means taking hands-off the controls.
In the Box
- IPS5 battery (up to 8 hours running time at 22 ° C)
- Charging cradle
- USB cable (charging and data transfer)
- Padded transport bag
- Wrist strap
- Quick guide
- Cleaning cloth
- Warranty card
Downloads
Pulsar Lexion Product Manual
Download
